Fabrication + Assembly
A combined fabrication and assembly order gives you one contact for engineering, production, and quality issues, and puts the panel design, the stack-up and the solder profile under one owner.
| Parameter | Scope |
|---|---|
| Fabrication | 1–20 layers; see the PCB capabilities tab for the full process window |
| Assembly | SMT, THT and mixed technology; single or double-sided |
| Panel design | Assembly panel, tooling rails and fiducials designed with the build in mind |
| Joint DFM | One review covering stack-up, impedance, footprints and assembly clearances |
| Lead time | Fabrication and assembly scheduled as one chain; lead time confirmed in your quotation |
| Accountability | Board and build defects handled by one owner; one contact for quality issue resolution |
| Commercial | One quote, one invoice, one shipment, priced in USD |
Rails, fiducials and break-off tabs are decided by the line that will run the board, with fabrication and assembly requirements reviewed together.
Finish and shelf life are chosen against your fine-pitch and press-fit requirements before the board is made.
Fabrication and kitting run in parallel against the same date, instead of the board waiting for parts or vice versa.
First builds where nobody yet knows whether a yield issue belongs to the board or to the process.
Boards where pad finish, via structure and paste volume have to be agreed as one decision.
Programs that would rather manage one purchase order than reconcile two.
Send the Gerber and BOM once; the quote covers fabrication, parts and assembly with a single lead time.
