Prototype PCBA
First builds exist to find problems, so DFM findings are shared with you before the build, and test results are provided as agreed in your quotation.
| Parameter | Scope |
|---|---|
| Batch size | 1–50 pcs |
| Fabrication | Expedited fabrication options depend on layer count, process requirements, and factory capacity. |
| Assembly time | Confirmed in your quotation, based on component availability |
| Sourcing | Turnkey, partial or consigned; send a kit list with consigned parts |
| Test | AOI, X-ray, ICT and FCT as selected on the RFQ; FCT needs your test plan |
| Feedback | DFM findings before the build; other records when agreed in the quotation |
| Revisions | Board revisions tracked separately so builds are never mixed |
Pad geometry and pin count are compared against the purchased part, to help identify package or pin-count mismatches before assembly.
Silkscreen, centroid rotation and datasheet pin 1 are cross-checked before placement, not after.
Tooling holes, edge keep-out and connector interference are reviewed before production, when changes are easier to manage.
An initial build that supports review of the assembled design against your test requirements.
Short cycles where each revision needs the same process so results stay comparable.
Small, documented builds for customer demos, EMC pre-scans and lab submissions.
Send Gerber, BOM and centroid; we come back with price, lead time and the DFM questions worth answering now.
